Inputs

• Inputs: 4 ,5, or 7 RCA Unbalanced, 4,5 or 7 XLR Balanced

• RJ45 - 4, 5, or 7 Channels of Dante Audio

• Input Sensitivity: 1.42 Vrms for full output

• Maximum Input Voltage: 2.7 Vrms

• Input Impedance: 100 kΩ

Outputs

• Amplifier Channels: 4, 5, or 7

• Power Output (8Ω): 230 watts per channel

• Power Output (4Ω): 300 watts per channel

• Power Output (8Ω Bridged Mono): 600 watts

• Minimum Speaker Load: 4 Ω

Performance

• Damping Factor: >450

• Total Harmonic Distortion: 0.04% (230 watts @ 8 ohms 20 Hz to 20 kHz)

• Signal to Noise: >102 dB, A-wtd ref Full Output

• Frequency Response: 10 Hz -20 kHz, ±1 dB

Control

• Remote Power Trigger: +12 VDC or Dry Contact Closure
